CPU

Qualocomm - CORTEX - A53 (1.2 GHz, 4 cores)

MEMORY

RAM 1GB DDR3; Flash 8GB eMMC (Default) /RAM 2GB DDR3; Flash 16GB eMMC (Optional), support external micro TF card, 32 GB

OS

Android 9.0

DISPLAY

5,5" (720 x 1280) HD Colorful LCD
Capacitive touch screen

KEYPAD

1 Power key, 1 physical functional keys, 3 in-screen touch keys (Menu, Back, Home)
CARD READERS:

Magstripe: Support 1/2/3 Magnetic track, bi-directional swiping, support ISO7811/7812
Smart Card: 1 IC slot, support 1.8V/3V/5V card, support ISO7816, EMV standard

Contactless: NFC 13.56MHz, support ISO/IEC 14443, Type A/B

COMMUNICATION

4G (FDD-LTE/TDD-LTE) + 3G (WCDMA) + 2G (GSM) (Optional)
WLAN: 2.4G,802.11 b/g/n Inner antenna

Bluetooth V4.2 + BLE

SECURITY

PCI PTS 5.x, EMV L1 & L2, PayPass, PayWave, Amex, TQM, CE, ROSH
POWER & BATTERY

Battery: 2200 mAh lithium, 7.4V (3000 mAh, 7.4V optional)
Input: AC100~240V, 50~60Hz, 0,3A

Output: DC5V, 2A

SIZE

L x W x H = 200mm x 80mm x 56mm
WEIGHT

470g including battery
ENVIRONMENTAL PARAMETERS:

Operating temperature: -10° to 50° C
Storing temperature: -20° to 60° C

Humidity: 10% to 90%, non-condensing MULTI-MEDIA

Built-in speaker, Microphone
PRINTER

2-inch 7.4V Thermal Printer, Paper Width: 58mm, Paper Roller Diameter: 40mm
DEVICE PORTS

1 micro-USB 2.0, 1 DC JACK, POGO PIN 5V--2A
SLOTS

SAM Card: 1 SIM Slot & 2 PSAM Slots (Default), 2 SIM Slots & 1 PSAM
Slot (Optional), 1 TF slot

CAMERA

5M Pixel FF Rear Camera; flash LED, Reads 1D & 2D Codes; matrix scanner (option)
GPS TRACKING

GPS, support AGPS
MULTIFUNCTIONAL DOCKING BASE (OPTIONAL)

Ports (1x Type-A USB 2.0 Host, 1 x RJ45 (RS232), 1 RJ45 (LAN),1 x Micro-USB (Charging), POGO Pins interface, Power Input DC 5V-2A
