Vertical reach 70.2 m Theoretical output 180 m3/h (125 m3/h)
Horizontal reach 63.5 m Theoretical pressure 8.3 MPa (12 MPa)
Depth reach 50.3+3 m Delivery cylinder diameter 260 mm
UnFolded reach 16.9 m Stroke length 2100 mm
Rotation ±360 ° Hydraulic system Open
Front outrigger spread L-R 12110 mm Hydraulic system oil pressure 32 MPa
Rear outrigger spread L-R 14990 mm Oil tank capacity 960 L
End hose length 3 m Water tank capacity 750+750 L
End hose diameter 125 mm Drive pump DanFoss
Pipeline size 125 mm Volume oF hopper 750 L
